Custom power press suppliers for wholesale

Company Advantages
1. WORLD adopts advanced and safet raw material. It comes with a wide range of electric motor powers
2. The establishment of quality control system ensures WORLD to provide best quality power press suppliers . It adopts pneumatic cylinder structure to avoid machine shaking caused by weight
3. The product has an extremely long service life through high-intensity detection. All its welded points are inspected by ultrasonic to ensure no leakage
4. With the comprehensive process visualization across all production stages, the product is guaranteed to be zero-defect.

Item		JX36-400	JX36-500	JX36-630	JX36-800	JX36-1000
Nominal Capacity	kn	400	5000	6300	8000	10000
Rated Tonnage Point	mm	9	12	12	12	12
Stoke Length	mm	300	300	350	350	400
Stroke Speed	spm	20-35	20-35	20-30	15-25	15-25
Max. Die Shut Height	mm	650	650	700	800	900
Die Shut Height Adjustment	mm	200	200	250	250	250
Table Size (FBxLR)	mm	1300×3000	1500×3000	1500×3600	2000×4000	2000×4000
Table Thickness	mm	220	220	250	250	250
Slide Bottom Size (FB-LR)	mm	1300×3000	1500×3000	1500×3600	2000×4000	2000×4000
Window Opening (FBxH)	mm	1000×650	1100×650	1200×700	1600×800	1600×900
Table Height	mm	710	710	710	710	710
Motor Power	kw	45	55	75	75	90
Overall Dimensions (LxWxH)	mm		3330x4650x 7250	3800x5400x 7700	4200x6150x 9200	4600x6150x 9900
Approximate Weight	t	80	90	120	150	190

Company Features
1. WORLD promotes the development of technology to improve the quality of power press suppliers .
2. We have been committed to environmental protection and sustainable development. During production, we do our best to reduce the negative impact, such as treating waste scientifically and reducing resources waste.
