WORLD Wholesale 30 ton power press machine high-Supply for wholesale

Company Advantages
1. WORLD undergoes four basic production processes which are all up to industry standards including high-temperature cooling, heating, disinfection, and drying. All its welded points are inspected by ultrasonic to ensure no leakage
2. The product helps improve the flexibility of working. Because it allows operators to perform maintenance and other tasks while it is in motion. Fabricated by heat treatment, its steel welded body has high rigidity
3. High performance and superior quality are the chief features of this product. Its simple design which has only a few moving parts helps cut maintenance costs

Item		Code	Unit	JW31-315	JW31-400	JW31-500
Nominal Capacity		Pe	kn	3150	4000	5000
Slide Stroke		s	mm	220	250	250
Slide Stroke Speed	Fixed	n	spm	30	25	20
	Variable (Optional)	n	spm	20-35	20-30	15-25
Max. Die Shut Height		H2	mm	550	600	650
Die Shut Height Adjustment		t	mm	120	120	120
Side Window Size	F-B	E	mm	850	900	1000
	Height	F	mm	480	520	650
Distance Between Uprights		G	mm	1350	1450	1650
Table Size	F-B	D	mm	850	900	1000
	L-R	C	mm	1250	1350	1500
	Thickness	H3	mm	190	200	220
Table Hole Diameter			mm	220	220	220
Slide Bottom Size	F-B	b	mm	800	850	950
	L-R	a	mm	1000	1100	1250
Table Surface Height		H1	mm	1215	1225	1225
Overall Dimensions	F-B	A	mm	2600	2700	3100
	L-R	B	mm	2200	2370	2600
	Height	H	mm	4550	4900	5400
Motor Power			kw	30	37	45
Weight (Approximate)			kg	30000	36500	47500

Company Features
1. Shanghai Yingxin World Machinery Co., Ltd. is equipped with strong research strength, having an R&D team dedicated to developing all types of new 30 ton power press machine .
2. Shanghai Yingxin World Machinery Co., Ltd. is dedicated to 'Good Faith', 'Better Services' and 'Best Attitude'. Get an offer!
