WORLD Top cnc power press machine at discount

Company Advantages
1. The tests for WORLD have been conducted. It has been tested in terms of flexibility, durability, accuracy, tolerances, fatigue resistance, etc. The product has a self-lubricating function
2. Good quality after-sales service is also an attraction for customers to trust WORLD. It has advantages in internal mechanical performance, such as smooth operation
3. The product operates stably and reliably. It can withstand running fatigue and is not easily affected by temperature and pressure. The clearance between connecting rod and slider has been eliminated to reduce force component impact and abrasion
4. The product is notable for its high energy efficiency. This product consumes little energy or power to finish its task. Its table length and width can be customized to better operation
5. It has the required strength. The elements of its mechanism are designed as per the involved stresses in the application. The product is equipped with Siemens main motor and Schneider electric components for further accuracy

                                                             Specification List:

Model				JH21-125L
Capacity			kN	1250
Nominal Stroke			mm	6
Slide Stroke			mm	10-160
SPM	Fixed		min-1	50
	Variable		min-1	40-60
Max. Die Height			mm	350
Die Height Adjustment			mm	80
Throat Depth			mm	350
Between Columns			mm	760
Bolster		LR	mm	1150
		FB	mm	680
		Thickness	mm	140
Bolster Opening			mm	φ260×50
(Up Hole Dia.×Depth×Low Hole Dia.)				×φ220
Slide Area		LR	mm	810
		FB	mm	500
Shank Hole		Dia.	mm	φ60
		Depth	mm	80
Main Motor Power			kW	11
Dimensions		FB	mm	1850
		LR	mm	1450
		H	mm	3250
Net Weight			kg	10700

Company Features
1. WORLD has become more and more influential in cnc power press machine industry. We continue to invest in advanced production facilities to connect our equipment, people and processes. This will finally help us improve productivity, quality, responsiveness, as well as the accuracy of decision making throughout the product lifecycle.
2. Our factory is located in an advantageous place. It is next to the raw material source and consumer market, which can greatly reduce the transportation cost.
3. We manage the global supply of products to our customers worldwide, including notably Japan, the US, and the UK. The international demand for our products demonstrates our ability to meet or exceed the needs of every customer. Shanghai Yingxin World Machinery Co., Ltd. insists on green development to build a better world together with our customers. Contact!
