WORLD Top a frame bushing press factory competitive factory

Company Advantages
1. WORLD has a professional design. It is designed by specialists who master the fundamentals of designing the most commonly used parts, elements, and units of various machines. Its welded steel body can withstand heavy industrial use
2. Thanks to the good comments from our long-term partners, WORLD has attracted more attention in the world. Fabricated by heat treatment, its steel welded body has high rigidity
3. The product has the advantage of stable mechanical properties. Having been treated under extremely cold temperatures, its mechanical components are tensile enough to withstand extreme industrial conditions. It has advantages in internal mechanical performance, such as smooth operation
4. The product is safe to use. It has been checked under anti-static testing and materials elements inspection to ensure users' safety. The clearance between connecting rod and slider has been eliminated to reduce force component impact and abrasion

Item		Code	Unit	JH21-25	JH21-45	JH21-60	JH21-80	JH21-100	JH21-125
Nominal Capacity		Pe	kn	250	450	600	800	1000	1250
Slide Stroke Length		S	mm	80	120	140	160	160	180
Slide Strokes	Fixed		spm	100	80	70	60	55	50
	Variable (optional)		spm	60-120	50-95	45-85	40-75	35-65	35-65
Max. Die Shut Height		H2	mm	250	270	300	320	335	350
Die Shut Height Adjustment		t	mm	50	60	70	80	90	90
Throat Depth		C1	mm	210	225	270	310	330	350
Distance Between Uprights		d1	mm	450	515	560	610	670	670
Slide Bottom Size	FB	b	mm	250	340	400	460	520	520
	LR	a	mm	360	410	480	540	620	620
Shank Hole Size	Diameter	d	mm	40	50	50	50	70	70
	Depth	I	mm	65	60	70	65	90	90
Table Size	FB	D	mm	400	440	520	600	640	680
	LR	C	mm	720	825	930	950	1060	1100
	Thickness	H3	mm	80	110	130	140	145	155
Table Hole Diameter		¢	mm	150	150	150	180	180	200
Overall Specs	FB	A	mm	1500	1585	1540	1765	2000	2040
	LR	B	mm	945	1075	1200	1200	1300	1320
	Height	H	mm	2120	2390	2570	2725	3010	3035
Motor Power			kw	3	5.5	5.5	7.5	7.5	11
Weight (approximate)			kg	2450	3550	5150	6450	8650	9550

Company Features
1. WORLD is a reliable company which is famous for its a frame bushing press . WORLD has a full set of quality control equipment imported to make sure the quality of hand power press machine .
2. Shanghai Yingxin World Machinery Co., Ltd. has a complete production line with advanced machine.
3. The efforts of improving the quality of high speed hydraulic press has been paid. Shanghai Yingxin World Machinery Co., Ltd. aims to improve the user experience and spread the brand reputation by word-of-mouth. Get more info!
