WORLD press master power press easy-operated at discount

Company Advantages
1. WORLD press master power press is delicately manufactured and reflects a high level of technology. It is one of the most beneficial and convenient workshop machinery
2. The product is widely used in various industries. Its double-hand control buttons give a safety guarantee for the operator
3. This product is highly regarded among customers, with high durability and high cost performance. The product will stop immediately once it is overload than 110% to protect both the press and the die

JW36 straight side power press uses H frame steel welded body which is under heat

treatment and ball ballasting treatment to release the welding stress. The body is just

 one time fixed on the CNC milling center table to machining all holes and surfaces.

In this way, the machining precision is much higher than normal process.The slide guides

 are four angles eight surfaces type and the gap can be adjusted on both front to rear

 side and left to right side. Precision is already ensured during machining and just need

to fine adjustment when installation or future maintenance.

Item		Code	Unit	JW36-110	JW36-160	JW36-200	JW36-250
Nominal Capacity			kn	1100	1600	2000	2500
Slide Stroke Length		S	mm	180	200	250	280
Slide Stroke Speed	Fixed		spm	50	45	35	30
	Variable (Optional)		spm	35-55	35-55	25-40	20-35
Max. Die Shut Height		H2	mm	400	450	500	550
Die Shut Height Adjustment		t	mm	90	100	110	120
Side Window Size	F-B	E	mm	650	800	900	950
	Height	F	mm	350	400	450	460
Distance Between Uprights		G	mm	1750	1900	2290	2570
Table Size	F-B	D	mm	700	760	900	1000
	L-R	C	mm	1650	1800	2200	2500
	Thickness	H3	mm	140	150	170	180
Slide Bottom Size	F-B	b	mm	600	700	800	900
	L-R	a	mm	1350	1500	1900	2200
Table Surface Height		H1	mm	1035	1035	1135	1235
Overall Dimensions	F-B	A	mm	2050	2400	2650	2900
	L-R	B	mm	2400	2650	3150	3450
	Height	H	mm	3450	3950	4280	4800
Motor Power			kw	11	18.5	22	30
Weight (Approximate)			kg	18000	22000	33000	42000

Company Features
1. Shanghai Yingxin World Machinery Co., Ltd. has a superb technical level for press master power press production.
2. Shanghai Yingxin World Machinery Co., Ltd. is always prepared to supply you with a complete assortment of services. Check it!
