WORLD power press supplier easy-operated for wholesale

Company Advantages
1. WORLD is carefully designed. Mechanical behavior such as statics, dynamics, the strength of materials, vibrations, reliability, and fatigue are taken into consideration. This product is designed for the really tough jobs that require high production, high tonnage, or variable controls
2. The product can significantly liberate people from heavy-duty and monotonous work, allowing people to spend time focusing on other important tasks. Fabricated by heat treatment, its steel welded body has high rigidity
3. This product is safe to use. It is equipped with emergency protection systems such as short circuit, overload, overpressure, and voltage loss. It is suitable for various kinds of fabrication work, such as the manufacturing of auto parts, household appliances, electronic parts, etc
4. The product is not likely to have dimension errors. During the testing stage, its sizes and shape have been checked under the precise measuring machines. Its table length and width can be customized to better operation

Item		JX36-400	JX36-500	JX36-630	JX36-800	JX36-1000
Nominal Capacity	kn	400	5000	6300	8000	10000
Rated Tonnage Point	mm	9	12	12	12	12
Stoke Length	mm	300	300	350	350	400
Stroke Speed	spm	20-35	20-35	20-30	15-25	15-25
Max. Die Shut Height	mm	650	650	700	800	900
Die Shut Height Adjustment	mm	200	200	250	250	250
Table Size (FBxLR)	mm	1300×3000	1500×3000	1500×3600	2000×4000	2000×4000
Table Thickness	mm	220	220	250	250	250
Slide Bottom Size (FB-LR)	mm	1300×3000	1500×3000	1500×3600	2000×4000	2000×4000
Window Opening (FBxH)	mm	1000×650	1100×650	1200×700	1600×800	1600×900
Table Height	mm	710	710	710	710	710
Motor Power	kw	45	55	75	75	90
Overall Dimensions (LxWxH)	mm		3330x4650x 7250	3800x5400x 7700	4200x6150x 9200	4600x6150x 9900
Approximate Weight	t	80	90	120	150	190

Company Features
1. Our factory incorporates the latest technological advances in manufacturing, machinery, and processes. This ensures a high level of consistency, accuracy, and quality in our production.
2. We take social responsibility. We are committed to protecting our precious environment and reducing the impact of our activities and our customers' activities. Check it!
