WORLD power press manufacturers in china high-Supply for customization

Company Advantages
1. Our strict raw material selection process ensures WORLD is always made of the finest materials. It has advantages in internal mechanical performance, such as smooth operation
2. Many of our customers say the product fits perfectly to their feet, and the product is not subject to deform or wear out even after times of wearing. It is suitable for various kinds of fabrication work, such as the manufacturing of auto parts, household appliances, electronic parts, etc
3. The quality test is conducted by professional team and the third parties as well. The brake system enables it to stop at any point, especially for the emergency stop

Item		JX36-400	JX36-500	JX36-630	JX36-800	JX36-1000
Nominal Capacity	kn	400	5000	6300	8000	10000
Rated Tonnage Point	mm	9	12	12	12	12
Stoke Length	mm	300	300	350	350	400
Stroke Speed	spm	20-35	20-35	20-30	15-25	15-25
Max. Die Shut Height	mm	650	650	700	800	900
Die Shut Height Adjustment	mm	200	200	250	250	250
Table Size (FBxLR)	mm	1300×3000	1500×3000	1500×3600	2000×4000	2000×4000
Table Thickness	mm	220	220	250	250	250
Slide Bottom Size (FB-LR)	mm	1300×3000	1500×3000	1500×3600	2000×4000	2000×4000
Window Opening (FBxH)	mm	1000×650	1100×650	1200×700	1600×800	1600×900
Table Height	mm	710	710	710	710	710
Motor Power	kw	45	55	75	75	90
Overall Dimensions (LxWxH)	mm		3330x4650x 7250	3800x5400x 7700	4200x6150x 9200	4600x6150x 9900
Approximate Weight	t	80	90	120	150	190

Company Features
1. Shanghai Yingxin World Machinery Co., Ltd. is a leading manufacturer of power press manufacturers in china with highly advanced production machines. We have professional technicians to produce finest power press working .
2. Professional technicians assures the high quality of 50 ton power press machine .
3. The quality of the mechanical press brake machine also relies on the strong technical force of WORLD. WORLD is committed to bringing endless benefits and success to each customer throughout the life cycle. Inquire now!
