WORLD power press machine design high-Supply for customization

Company Advantages
1. WORLD is produced in a safe and clean environment. Its top oil house has been tested by an oil bath to guarantee no leaking
2. Our all-round service will definitely satisfy every customer from Shanghai Yingxin World Machinery Co., Ltd.. The brake system enables it to stop at any point, especially for the emergency stop
3. The product has good temperature withstanding capability. Its mechanical properties will not be affected by the variations in temperature. The product is equipped with Siemens main motor and Schneider electric components for further accuracy

Item		JX36-400	JX36-500	JX36-630	JX36-800	JX36-1000
Nominal Capacity	kn	400	5000	6300	8000	10000
Rated Tonnage Point	mm	9	12	12	12	12
Stoke Length	mm	300	300	350	350	400
Stroke Speed	spm	20-35	20-35	20-30	15-25	15-25
Max. Die Shut Height	mm	650	650	700	800	900
Die Shut Height Adjustment	mm	200	200	250	250	250
Table Size (FBxLR)	mm	1300×3000	1500×3000	1500×3600	2000×4000	2000×4000
Table Thickness	mm	220	220	250	250	250
Slide Bottom Size (FB-LR)	mm	1300×3000	1500×3000	1500×3600	2000×4000	2000×4000
Window Opening (FBxH)	mm	1000×650	1100×650	1200×700	1600×800	1600×900
Table Height	mm	710	710	710	710	710
Motor Power	kw	45	55	75	75	90
Overall Dimensions (LxWxH)	mm		3330x4650x 7250	3800x5400x 7700	4200x6150x 9200	4600x6150x 9900
Approximate Weight	t	80	90	120	150	190

Company Features
1. In China, the quality of Shanghai Yingxin World Machinery Co., Ltd. production is at the leading level.
2. We are delighted that our stunning development has won many awards. These awards are a testament to the continued care and attention we put into all of the projects.
3. We value sustainable development. We get sustainability principles into the mission, vision, and values of our company and we have positioned sustainable development management as the base for all activities.
