WORLD manufacturer of power press easy-operated at discount

Company Advantages
1. manufacturer of power press 's design idea is based on the search for a high-quality life standard. The product is equipped with Siemens main motor and Schneider electric components for further accuracy
2. This product is favored by the majority of the people and shows the broad market application prospects of this product. Processed by sandblasting, it has enhanced fatigue resistance
3. This product features high precision. It can produce an exact result every single time and repeat the exact same task with the same level. The designing and versatility of the product give users an advantage of moving its freely around the workplace
4. The product features a clean appearance. It is coated with a special layer to effectively prevent adhesion of dust or oil smoke when being placed. The product is distinguished by low electricity consumption

Item		Code	Unit	JW31-160	JW31-200	JW31-250
Nominal Capacity		Pe	kn	1600	2000	2500
Slide Stroke		s	mm	180	200	220
Slide Stroke Speed	Fixed	n	spm	45	35	30
	Variable (Optional)	n	spm	35-55	35-55	20-35
Max. Die Shut Height		H2	mm	400	450	500
Die Shut Height Adjustment		t	mm	110	110	120
Side Window Size	F-B	E	mm	650	750	800
	Height	F	mm	350	420	430
Distance Between Uprights		G	mm	1100	1200	1300
Table Size	F-B	D	mm	650	750	800
	L-R	C	mm	1000	1100	1200
	Thickness	H3	mm	165	180	190
Table Hole Diameter			mm	180	200	200
Slide Bottom Size	F-B	b	mm	600	700	750
	L-R	a	mm	750	850	950
Table Surface Height		H1	mm	1005	1115	1205
Overall Dimensions	F-B	A	mm	2200	2300	2500
	L-R	B	mm	1780	2000	2050
	Height	H	mm	3800	4200	4500
Motor Power			kw	15	18.5	22
Weight (Approximate)			kg	16000	22000	27500

Item		Code	Unit	JW31-315	JW31-400	JW31-500
Nominal Capacity		Pe	kn	3150	4000	5000
Slide Stroke		s	mm	220	250	250
Slide Stroke Speed	Fixed	n	spm	30	25	20
	Variable (Optional)	n	spm	20-35	20-30	15-25
Max. Die Shut Height		H2	mm	550	600	650
Die Shut Height Adjustment		t	mm	120	120	120
Side Window Size	F-B	E	mm	850	900	1000
	Height	F	mm	480	520	650
Distance Between Uprights		G	mm	1350	1450	1650
Table Size	F-B	D	mm	850	900	1000
	L-R	C	mm	1250	1350	1500
	Thickness	H3	mm	190	200	220
Table Hole Diameter			mm	220	220	220
Slide Bottom Size	F-B	b	mm	800	850	950
	L-R	a	mm	1000	1100	1250
Table Surface Height		H1	mm	1215	1225	1225
Overall Dimensions	F-B	A	mm	2600	2700	3100
	L-R	B	mm	2200	2370	2600
	Height	H	mm	4550	4900	5400
Motor Power			kw	30	37	45
Weight (Approximate)			kg	30000	36500	47500

Company Features
1. Equipped with high technology, WORLD manufactures manufacturer of power press with high recognition. We have many employees work in our R&D units. They always cooperate with other peer R&D institution or agencies in China to improve themselves and come up with the best innovations.
2. Thanks to the solid technical foundation, Shanghai Yingxin World Machinery Co., Ltd. stands out in the power press mechanism industry.
3. All R&D project will be serviced by our experts and technicians who have abundant knowledge of the products in the industry. Thanks to their professionalism, our company is doing better in product innovations. We will continue to improve the quality of our products and services to increase customer satisfaction and maintain our position as the world's leading manufacturer of high-quality products. Get quote!
