WORLD hydraulic wheel press Supply for drawing

Company Advantages
1. Using the latest technology and high-grade materials,WORLD hydraulic wheel press is manufactured in compliance with guidelines of fine production methods. It has advantages in internal mechanical performance, such as smooth operation
2. World Press Machine believes that the quality is the soul of an enterprise. The product has a self-lubricating function
3. It has great performance superiority compared with other products.
4. The quality of WORLD product is widely recognized by global customers. It is one of the most beneficial and convenient workshop machinery
5. hydraulic wheel press reaches the advanced level of the industry. The product is quiet during the operation

metal forming four columu 400 ton hydraulic press



Four column hydraulic press is applicable for drawing, bending, flanging, cold extruding and blanking process for metal materials. It is also applicable for adjusting, press-in and forming process for powder and abrasive products, plastic and insulation materials. The hydraulic press adopts 3 beam and 4 column compact structure, simple, economic and practical. Adopting button common control with two operation modes: adjustment or two hand single cycle operation. Preset stroke forming or preset pressure forming process can be selected.

MODEL			YW27-200	YW27-315	YW27-400	YW27-400A	YW27-400B	YW27-500	YW27-630
Capacity		kN	2000	3150	2000	4000	4000	5000	6300
Hydraulic cushion capacity		kN	1200	1500	1500	2000	1000	1500	2000
Slide Stroke		mm	800	1000	1000	1200	500	1000	1500
Hydraulic cushion Stroke		mm	260	300	350	350	200	300	400
Max. Shut Height		mm	1200	1600	1500	2000	1100	1400	2000
Bolster movement distance		mm			2000	2400		1600	2700
Slide Speed	Idle Stroke	mm/s	220	200	200	250	180	220	200
	Pressing	mm/s	15-25	10-15	9-15	10-25	10-25	8-20	6-15
	Return	mm/s	160	150	150	150	120	160	150
Ejecting Speed	Eject	mm/s	60	60	60	60	60	80	80
	Return	mm/s	100	100	100	80	80	120	100
Bolster Size	LR	mm	1000	2500	2700	3000	1700	2000	4500
	FB	mm	1000	1600	1500	2000	1400	1400	2500
Main Motor Power		kW	15	22	44	44	44	44	67

World brand specializing in power press machine , hydraulic press machine , NC feeder . Such as the company has an excellent technology development team, team members have good professional basis and rich design experience, the team members including mechanical design engineer, engineer, electric control system of assembly and debugging engineer, after-sales service engineers, can provide customers with automation technology in the field of all kinds of application solutions .

Company Features
1. As a hydraulic wheel press supplier, WORLD has been committed to improving quality and professional services. The factory has been adhering to a strict quality management system. From materials purchase to the last stage of production, we make sure products to strictly meet the related national standards stipulated for this industry.
2. We have become a competent partner of many industrial companies and distributors. Most of whom from Asia, Europe, and America have finished many projects with us.
3. Professionals are our valuable assets. They have deep knowledge of specific end markets. This enables the company to develop customized solutions to meet specific customer requirements. Our firm has a sustainability target to reduce the ecological footprint and preserve natural resources and reduce energy and water intake.
