WORLD double elephant power press at discount

Company Advantages
1. WORLD is created throughout a series of production processes which include raw material extraction, raw material process, and quality inspections. Its welded steel body can withstand heavy industrial use
2. Shanghai Yingxin World Machinery Co., Ltd. has a complete quality control system. Its pressure, speed, and operation mode can be adjusted based on needs
3. The application of quality surveillance system effectively guarantees the quality of the product. All its welded points are inspected by ultrasonic to ensure no leakage
4. This product is examed on the international standards instead of the national rules. It is one of the most beneficial and convenient workshop machinery
5. By improving production plan and adjusting crafts installation, WORLD has been always producing double elephant power press with high performance. Its top oil house has been tested by an oil bath to guarantee no leaking

Item		Code	Unit	JW31-315	JW31-400	JW31-500
Nominal Capacity		Pe	kn	3150	4000	5000
Slide Stroke		s	mm	220	250	250
Slide Stroke Speed	Fixed	n	spm	30	25	20
	Variable (Optional)	n	spm	20-35	20-30	15-25
Max. Die Shut Height		H2	mm	550	600	650
Die Shut Height Adjustment		t	mm	120	120	120
Side Window Size	F-B	E	mm	850	900	1000
	Height	F	mm	480	520	650
Distance Between Uprights		G	mm	1350	1450	1650
Table Size	F-B	D	mm	850	900	1000
	L-R	C	mm	1250	1350	1500
	Thickness	H3	mm	190	200	220
Table Hole Diameter			mm	220	220	220
Slide Bottom Size	F-B	b	mm	800	850	950
	L-R	a	mm	1000	1100	1250
Table Surface Height		H1	mm	1215	1225	1225
Overall Dimensions	F-B	A	mm	2600	2700	3100
	L-R	B	mm	2200	2370	2600
	Height	H	mm	4550	4900	5400
Motor Power			kw	30	37	45
Weight (Approximate)			kg	30000	36500	47500

Company Features
1. Shanghai Yingxin World Machinery Co., Ltd. is independent in R&D, production, and sales of . We are a reputable company in the China market.
2. Our company has a strong backup force comprising a pool of talents, mainly R&D talents. They have specialized in research and development and customized services for years. Their strong competence and expertise enable us to offer distinguished products for clients.
3. While devotes to the R&D of double elephant power press , Shanghai Yingxin World Machinery Co., Ltd. has established our own unique profession leading status. Check it!
