WORLD c frame press for sale Supply longer service life1

Company Advantages
1. WORLD has passed the necessary tests. They include functionality testing, strength testing, stiffness testing, wear testing, corrosion testing, and friction testing. The product will stop immediately once it is overload than 110% to protect both the press and the die
2. This product is important in many industries. It plays an important role in increasing labor productivity and reducing the cost of human labor. Its PLC control system can be a Panasonic or Mitsubishi brand
3. It continuously set and then exceed the standard for what it should be. Its top oil house has been tested by an oil bath to guarantee no leaking

Item		Code	Unit	JH21-25	JH21-45	JH21-60	JH21-80	JH21-100	JH21-125
Nominal Capacity		Pe	kn	250	450	600	800	1000	1250
Slide Stroke Length		S	mm	80	120	140	160	160	180
Slide Strokes	Fixed		spm	100	80	70	60	55	50
	Variable (optional)		spm	60-120	50-95	45-85	40-75	35-65	35-65
Max. Die Shut Height		H2	mm	250	270	300	320	335	350
Die Shut Height Adjustment		t	mm	50	60	70	80	90	90
Throat Depth		C1	mm	210	225	270	310	330	350
Distance Between Uprights		d1	mm	450	515	560	610	670	670
Slide Bottom Size	FB	b	mm	250	340	400	460	520	520
	LR	a	mm	360	410	480	540	620	620
Shank Hole Size	Diameter	d	mm	40	50	50	50	70	70
	Depth	I	mm	65	60	70	65	90	90
Table Size	FB	D	mm	400	440	520	600	640	680
	LR	C	mm	720	825	930	950	1060	1100
	Thickness	H3	mm	80	110	130	140	145	155
Table Hole Diameter		¢	mm	150	150	150	180	180	200
Overall Specs	FB	A	mm	1500	1585	1540	1765	2000	2040
	LR	B	mm	945	1075	1200	1200	1300	1320
	Height	H	mm	2120	2390	2570	2725	3010	3035
Motor Power			kw	3	5.5	5.5	7.5	7.5	11
Weight (approximate)			kg	2450	3550	5150	6450	8650	9550

1. The main body is welded with high quality steel plate. It will be heat treated and ball blasting treated to release the stress and improve the rigidity.

Company Features
1. We have a skillful management team. They can find the biggest challenges for manufacturing including generating sales at good margins and ensuring productivity from automation.
2. Shanghai Yingxin World Machinery Co., Ltd. has always been pursuing excellence and professionalism in the field of c frame press for sale . Inquire online!
