WORLD 20 ton power press price Suppliers at discount

Company Advantages
1. WORLD meets mandatory electrical safety requirements. It has to pass the following tests: high voltage test, leakage current test, insulation resistance test, and ground continuity test. The product will stop immediately once it is overload than 110% to protect both the press and the die
2. Shanghai Yingxin World Machinery Co., Ltd. is well-funded with adequate 20 ton power press price supply and thoughtful service. The designing and versatility of the product give users an advantage of moving its freely around the workplace
3. The product is not prone to accumulate dust and particles. It is designed with a protective housing for parts and other precision components to avoid dust deposition. It comes with a wide range of electric motor powers
4. The product is highly resilient to vibration and impact. Its optimized internal clearance and bearings help resist the effects of extreme vibration. Its pressure, speed, and operation mode can be adjusted based on needs
5. The product has a relatively simple operating system. It combines a powerful processing flow with simple operation instruction to finish its tasks. The ball bearing has high wear resistance, avoiding generating big gear noise due to abrasion

 Specifications:



ITEMS		UNIT	J23-6.3	J23-10	J23-16	J23-25	J23-35	J23-40	J23-63	JB23-63	J23-80	J23-100	J23-125
Capacity		KN	63	100	160	250	350	400	630	630	800	1000	1250
Nominal stroke		mm	2	2	2	2.5	3.5	6	6	7	7	7	8
Slide stroke length		mm	35	45	55	65	80	90	110	110	120	140	150
Stroke times per minute		spm	170	145	125	55	50	45	50	40	38	38	38
Max. Die set height		mm	150	180	220	270	290	320	360	390	440	480	500
Die shut height adjustment		mm	30	35	45	55	60	65	80	80	90	100	100
Throat depth		mm	110	130	160	200	220	250	260	310	350	380	390
Distance between uprights		mm	150	180	220	270	280	340	350	420	450	560	550
Slide bottom size	L-R	mm	140	170	200	250	250	300	300	400	430	540	540
	F-B	mm	120	150	180	220	220	260	260	360	360	480	480
Stemhole size	Diameter	mm	30	30	40	40	40	50	50	50	60	60	60
	Depth	mm	55	55	60	60	60	70	70	70	75	75	75
Bolster size	L-R	mm	310	370	450	560	610	700	760	860	950	1080	1100
	F-B	mm	200	240	300	370	400	460	480	570	650	710	720
	Thickness	mm	30	35	40	50	60	65	80	80	100	120	130
Table hole diameter		mm	60	80	100	120	130	150	180	180	200	220	240
Max. inclinable angle		°	45	35	35	30	30	30	20	20	20	15	13
Bolster surface height		mm	750	730	750	800	815	850	810	850	850	850	860
Over all dimensions	L-R	mm	620	665	847	950	1058	1335	1350	1500	1715	1790	1790
	F-B	mm	780	900	1150	1345	1460	1721	1810	1958	2060	2404	2504
	Height	mm	1503	1658	1910	2130	2225	2488	2740	2868	3290	3625	3715
Distance between foundation bolts	L-R	mm	314	394	450	600	650	750	850	920	1010	1130	1110
	F-B	mm	530	610	780	920	1020	1060	1180	1300	1360	1550	1710
Motor power		kw	0.75	1.1	1.5	2.2	4	5.5	5.5	7.5	7.5	11	11
Weight		kg	400	576	1085	1780	2650	3540	4550	5500	7390	10800	12035

Features:

1)Adopts horizontally placed crankshaft.

2)Adopt rolling bearing instead of copper bush with lower noise and longer service life.

3)Casting body, inclinable body.

4)J23-80 and the upon models adopt balance cylinders.

5)Manual shut height adjustment with scale display.

6)Rigid rotated bond clutch.

Company Features
1. Shanghai Yingxin World Machinery Co., Ltd. has many years of experience in delivering to the Chinese market and is an approved vendor in the industry.
2. The factory enjoys a geographical advantage. It is near to a broad range of high-quality raw materials suppliers, which benefits us in sourcing raw materials at a relatively low price yet high quality.
3. Making the company that a world 20 ton power press price supplier is the lifelong pursuit of each WORLD Individual. Please contact.
