Latest plate and frame filter press operation for business longer service life

Company Advantages
1. WORLD will go through the rough machining process such as material cutting, as well as the finish machining process such as polishing or plating. Adopting the hydraulic system, it needs little maintenance
2. This product will reduce the need for the workforce for its highly advanced system. It will directly cut down labor costs. Its welded steel body can withstand heavy industrial use
3. The product is distinguished by earthquake resistance. Made of heavy-duty materials and designed with strong construction, it can resist any form of sharp vibrations. The designing and versatility of the product give users an advantage of moving its freely around the workplace

Item		Code	Unit	JH21-25	JH21-45	JH21-60	JH21-80	JH21-100	JH21-125
Nominal Capacity		Pe	kn	250	450	600	800	1000	1250
Slide Stroke Length		S	mm	80	120	140	160	160	180
Slide Strokes	Fixed		spm	100	80	70	60	55	50
	Variable (optional)		spm	60-120	50-95	45-85	40-75	35-65	35-65
Max. Die Shut Height		H2	mm	250	270	300	320	335	350
Die Shut Height Adjustment		t	mm	50	60	70	80	90	90
Throat Depth		C1	mm	210	225	270	310	330	350
Distance Between Uprights		d1	mm	450	515	560	610	670	670
Slide Bottom Size	FB	b	mm	250	340	400	460	520	520
	LR	a	mm	360	410	480	540	620	620
Shank Hole Size	Diameter	d	mm	40	50	50	50	70	70
	Depth	I	mm	65	60	70	65	90	90
Table Size	FB	D	mm	400	440	520	600	640	680
	LR	C	mm	720	825	930	950	1060	1100
	Thickness	H3	mm	80	110	130	140	145	155
Table Hole Diameter		¢	mm	150	150	150	180	180	200
Overall Specs	FB	A	mm	1500	1585	1540	1765	2000	2040
	LR	B	mm	945	1075	1200	1200	1300	1320
	Height	H	mm	2120	2390	2570	2725	3010	3035
Motor Power			kw	3	5.5	5.5	7.5	7.5	11
Weight (approximate)			kg	2450	3550	5150	6450	8650	9550

Company Features
1. Shanghai Yingxin World Machinery Co., Ltd. is becoming more competitive in manufacturing and marketing in today's fierce market competition.
2. The spreading fame of plate and frame filter press operation also indicates the high quality.
3. Seeking the harmonious development of WORLD and society will make great contributions to the hydraulic deep drawing press machine industry. Welcome to visit our factory!
