Latest c frame table for business at discount

Place of Origin:
Jiangsu China
Payment:
L/C, T/T
MOQ:
1
Model:
JH21-100
Brand:
WORLD
Inquiry
Supply Ability
2000 Unit/Units per Year
Start Port
Shanghai China
Material
Metal
Delivery Time
30 days
Certification
CE, CCC
Availability
OEM
Company Advantages
1. WORLD has been strictly tested for evaluating conformance to quality over various footwear parameters. These include visual, chemical and physical tests. The high-quality friction discs ensure its long service life
2. Through an arduous efforts of all the staffs, WORLD has become a scaled and specialized c frame table company. Its top oil house has been tested by an oil bath to guarantee no leaking
3. The quality of this product has been recognized by many international certifications. Its simple design which has only a few moving parts helps cut maintenance costs







Item
Code
Unit
JH21-25
JH21-45
JH21-60
JH21-80
JH21-100
JH21-125
Nominal Capacity
Pe
kn
250
450
600
800
1000
1250
Slide Stroke Length
S
mm
80
120
140
160
160
180
Slide Strokes
Fixed

spm
100
80
70
60
55
50
Variable (optional)

spm
60-120
50-95
45-85
40-75
35-65
35-65
Max. Die Shut Height
H2
mm
250
270
300
320
335
350
Die Shut Height Adjustment
t
mm
50
60
70
80
90
90
Throat Depth
C1
mm
210
225
270
310
330
350
Distance Between Uprights
d1
mm
450
515
560
610
670
670
Slide Bottom Size
FB
b
mm
250
340
400
460
520
520
LR
a
mm
360
410
480
540
620
620
Shank Hole Size
Diameter
d
mm
40
50
50
50
70
70
Depth
I
mm
65
60
70
65
90
90
Table Size
FB
D
mm
400
440
520
600
640
680
LR
C
mm
720
825
930
950
1060
1100
Thickness
H3
mm
80
110
130
140
145
155
Table Hole Diameter
¢
mm
150
150
150
180
180
200
Overall Specs
FB
A
mm
1500
1585
1540
1765
2000
2040
LR
B
mm
945
1075
1200
1200
1300
1320
Height
H
mm
2120
2390
2570
2725
3010
3035
Motor Power

kw
3
5.5
5.5
7.5
7.5
11
Weight (approximate)

kg
2450
3550
5150
6450
8650
9550
Advantage:


1. The main body is welded with high quality steel plate. It will be heat treated and ball blasting treated to release the stress and improve the rigidity.

2. The press adopts Panasonic or Omron PLC with high stability and longer service life.

3. The wet cultch produced by World is made up of the best seals, bearing and friction discs. It features lower noise and longer service life.

4. The control panel includes double hand buttons and emergency stop button and foot pedal control switch is optional.

5. The press is equipped with auto lubrication pump and it is easy for maintenance.

6. The hydraulic overload protected pump is used to protect the press and the die from overloading.

7. The motorized slide adjusting device is adopted with a thin brake motor and operated with push buttons. It offers stable positioning accuracy and quick adjustment.
