high-qualtiy mechanical press machine specification for business at discount

Company Advantages
1. WORLD is made up of superior raw material using the latest technology. The brake system enables it to stop at any point, especially for the emergency stop
2. Shanghai Yingxin World Machinery Co., Ltd. has a wealth of production capabilities, strict process and complete quality management system. It comes with a wide range of electric motor powers
3. Our company has passed the ISO9001quality system certification, providing a more reliable guarantee for the quality of the product. The product is distinguished by low electricity consumption
4. Our perfect quality control systems insure high quality and reliability of this product. Its double-hand control buttons give a safety guarantee for the operator

Item		Code	Unit	JW36-110	JW36-160	JW36-200	JW36-250
Nominal Capacity			kn	1100	1600	2000	2500
Slide Stroke Length		S	mm	180	200	250	280
Slide Stroke Speed	Fixed		spm	50	45	35	30
	Variable (Optional)		spm	35-55	35-55	25-40	20-35
Max. Die Shut Height		H2	mm	400	450	500	550
Die Shut Height Adjustment		t	mm	90	100	110	120
Side Window Size	F-B	E	mm	650	800	900	950
	Height	F	mm	350	400	450	460
Distance Between Uprights		G	mm	1750	1900	2290	2570
Table Size	F-B	D	mm	700	760	900	1000
	L-R	C	mm	1650	1800	2200	2500
	Thickness	H3	mm	140	150	170	180
Slide Bottom Size	F-B	b	mm	600	700	800	900
	L-R	a	mm	1350	1500	1900	2200
Table Surface Height		H1	mm	1035	1035	1135	1235
Overall Dimensions	F-B	A	mm	2050	2400	2650	2900
	L-R	B	mm	2400	2650	3150	3450
	Height	H	mm	3450	3950	4280	4800
Motor Power			kw	11	18.5	22	30
Weight (Approximate)			kg	18000	22000	33000	42000

Company Features
1. We adopt world-advanced technology when manufacturing mechanical press machine specification .
2. Shanghai Yingxin World Machinery Co., Ltd. faithfully hopes to establish partnerships with customers around the world. Check now!
