High-quality power press parts for business at discount

Company Advantages
1. The raw materials of WORLD are selected by our team of professionals who have visited dozens of raw material suppliers and analyzed the data through high-intensity test experiments. It is suitable for various kinds of fabrication work, such as the manufacturing of auto parts, household appliances, electronic parts, etc
2. This product is widely used and has great market potential. It adopts pneumatic cylinder structure to avoid machine shaking caused by weight
3. power press parts is being increasingly important and widely applied because of advantages. It is one of the most beneficial and convenient workshop machinery
4. power press parts with full types is available in Shanghai Yingxin World Machinery Co., Ltd.. Fabricated by heat treatment, its steel welded body has high rigidity
5. Apart from the performance of , the other characteristics also contribute to the popularity of power press parts . Its top oil house has been tested by an oil bath to guarantee no leaking

Item		Code	Unit	JH21-25	JH21-45	JH21-60	JH21-80	JH21-100	JH21-125
Nominal Capacity		Pe	kn	250	450	600	800	1000	1250
Slide Stroke Length		S	mm	80	120	140	160	160	180
Slide Strokes	Fixed		spm	100	80	70	60	55	50
	Variable (optional)		spm	60-120	50-95	45-85	40-75	35-65	35-65
Max. Die Shut Height		H2	mm	250	270	300	320	335	350
Die Shut Height Adjustment		t	mm	50	60	70	80	90	90
Throat Depth		C1	mm	210	225	270	310	330	350
Distance Between Uprights		d1	mm	450	515	560	610	670	670
Slide Bottom Size	FB	b	mm	250	340	400	460	520	520
	LR	a	mm	360	410	480	540	620	620
Shank Hole Size	Diameter	d	mm	40	50	50	50	70	70
	Depth	I	mm	65	60	70	65	90	90
Table Size	FB	D	mm	400	440	520	600	640	680
	LR	C	mm	720	825	930	950	1060	1100
	Thickness	H3	mm	80	110	130	140	145	155
Table Hole Diameter		¢	mm	150	150	150	180	180	200
Overall Specs	FB	A	mm	1500	1585	1540	1765	2000	2040
	LR	B	mm	945	1075	1200	1200	1300	1320
	Height	H	mm	2120	2390	2570	2725	3010	3035
Motor Power			kw	3	5.5	5.5	7.5	7.5	11
Weight (approximate)			kg	2450	3550	5150	6450	8650	9550

Company Features
1. Shanghai Yingxin World Machinery Co., Ltd. is a global high-end power press parts manufacturing enterprise integrating R&D, production, sales and service. World Press Machine adopts advanced product process from other countries.
2. Shanghai Yingxin World Machinery Co., Ltd. constantly enhances the company's core competitiveness.
3. WORLD is a manufacturer that focuses on improving the quality of c frame power press manufacturers . We recognize that the key to every product development and successful customer outcome is our internal culture of innovation. We embrace continuous improvement and change, which positions us and, by extension our customers, for the future.
