Custom hydraulic h press at discount

Company Advantages
1. WORLD is processed by different advanced machines such as CNC cutting machine, lathe, drilling machine, etc. All these machines are in charge of professional technicians. The ground helical gear or herringbone gear makes the moving more stable with lower noise
2. The reasons that the product is widely used in industries are mainly due to the fact that using this product can cut energy costs while maintaining high productivity. The high-quality seals in the hydraulic system offer excellent sealing performance
3. All of our hydraulic h press can be designed and customized, including pattern, logo and so on. The product is quiet during the operation

                                                             Specification List：

Model				JH21-200L
Capacity			kN	2000
Nominal Stroke			mm	8
Slide Stroke			mm	19-180
SPM	Fixed		min-1	45
	Variable		min-1	30-40
Max. Die Height			mm	450
Die Height Adjustment			mm	110
Throat Depth			mm	390
Between Columns			mm	870
Bolster		LR	mm	1400
		FB	mm	760
		Thickness	mm	160
Bolster Opening			mm	φ300×50
(Up Hole Dia.×Depth×Low Hole Dia.)				×φ260
Slide Area		LR	mm	920
		FB	mm	600
Shank Hole		Dia.	mm	φ65
		Depth	mm	90
Main Motor Power			kW	18.5
Dimensions		FB	mm	2500
		LR	mm	1580
		H	mm	3420
Net Weight			kg	17950

Company Features
1. Shanghai Yingxin World Machinery Co., Ltd. has gained a great reputation at home and abroad. We have a solid foundation in developing and manufacturing hydraulic h press .
2. We have a team of highly trained and educated professionals. They explore and push the boundaries of new technological frontiers that drive productivity, quality and cost savings.
3. High quality products, reasonable prices, high capacity and swift delivery are Shanghai Yingxin World Machinery Co., Ltd.'s core aims. Get an offer!
