WORLD hydraulic hot press machine best factory price for flanging

Company Advantages
1. The production of WORLD is handled by the most advanced production equipment. The ball bearing has high wear resistance, avoiding generating big gear noise due to abrasion
2. Our service team allows customers understand hydraulic hot press machine control specifications and realize in the overall product offering. The designing and versatility of the product give users an advantage of moving its freely around the workplace
3. We closely monitor and control the quality in every stage to extend the lifespan of the product. Processed by sandblasting, it has enhanced fatigue resistance
4. The product is quality-assured as a strict quality control system is carried in our company. Its double-hand control buttons give a safety guarantee for the operator
5. An optimal system is established in order to satisfy customer demands 100%. The product has a self-lubricating function

Four Column Hydraulic Workshop Press Price 400 Ton Press Machines

  Four column hydraulic press is applicable for drawing, bending, flanging, cold extruding and blanking process for metal materials. It is also applicable for adjusting, press-in and forming process for powder and abrasive products, plastic and insulation materials. The hydraulic press adopts 3 beam and 4 column compact structure, simple, economic and practical. Adopting button common control with two operation modes: adjustment or two hand single cycle operation. Preset stroke forming or preset pressure forming process can be selected.

MODEL			YW27-200	YW27-315	YW27-400	YW27-400A	YW27-400B	YW27-500	YW27-630
Capacity		kN	2000	3150	2000	4000	4000	5000	6300
Hydraulic cushion capacity		kN	1200	1500	1500	2000	1000	1500	2000
Slide Stroke		mm	800	1000	1000	1200	500	1000	1500
Hydraulic cushion Stroke		mm	260	300	350	350	200	300	400
Max. Shut Height		mm	1200	1600	1500	2000	1100	1400	2000
Bolster movement distance		mm			2000	2400		1600	2700
Slide Speed	Idle Stroke	mm/s	220	200	200	250	180	220	200
	Pressing	mm/s	15-25	10-15	9-15	10-25	10-25	8-20	6-15
	Return	mm/s	160	150	150	150	120	160	150
Ejecting Speed	Eject	mm/s	60	60	60	60	60	80	80
	Return	mm/s	100	100	100	80	80	120	100
Bolster Size	LR	mm	1000	2500	2700	3000	1700	2000	4500
	FB	mm	1000	1600	1500	2000	1400	1400	2500
Main Motor Power		kW	15	22	44	44	44	44	67

Company Features
1. With years of devotion to developing and manufacturing , Shanghai Yingxin World Machinery Co., Ltd. is proud to gradually become stronger in this field.
2. This company has established a strong client base. By gaining deep insight into buyers' purchasing tendency, we have upgraded our products to better cater to clients. This helps us grow stronger to win more customers.
3. We will maintain the quality, integrity, and respect for our values. It's all about producing world-class products designed to improve our customers' business. Get quote!
