WORLD high-performance manufacturer of power press for business competitive factory

Company Advantages
1. WORLD goes through various tests. Its materials, mechanical parts, and other components will be inspected and tested by a specific quality control team. The high-quality friction discs ensure its long service life
2. [企业简称] Actively strengthen technical exchanges and cooperation with well-known enterprises in the same industry, and widely apply the new techniques and technologies learned in production, and continuously improve and optimize agricultural machinery and equipment, so that the production manufacturer of power press no matter in terms of performance , quality, appearance, etc. are superior to other similar products, and have more competitive advantages in the market.
3. The product features an easy operation. It has a relatively simple operating system combining a powerful processing flow and provides simple operation instruction. With a quality servo motor, it is highly efficient
4. The product has the advantage of strong compatibility. It can perfectly work with other mechanical systems to bring out the best results. The high-quality seals in the hydraulic system offer excellent sealing performance
5. The product can bear the most demanding industrial conditions. It is made of heavy-duty materials such as steel alloys and is not prone to rust and corrosion. The product is distinguished by low electricity consumption

The JW31 160 Ton High-Speed Automatic Power Press Machine is state-of-the-art industrial equipment designed for precision metal forming and stamping operations. With a high tonnage capacity of 160 tons, this power press machine delivers exceptional force and accuracy for various manufacturing applications. Its high-speed automatic operation ensures efficient production processes while maintaining superior quality and consistency in output. Equipped with advanced features and controls, the JW31 power press machine offers versatility and reliability in handling a wide range of materials and forming tasks. Whether used in automotive, electronics, or other industries, this machine excels in shaping and transforming metal parts with precision and speed. Backed by JW31's reputation for quality and performance, this power press machine is a trusted choice for businesses seeking to enhance their production capabilities and meet demanding manufacturing requirements.

Item		Code	Unit	JW31-160	JW31-200	JW31-250
Nominal Capacity		Pe	kn	1600	2000	2500
Slide Stroke		s	mm	180	200	220
Slide Stroke Speed	Fixed	n	spm	45	35	30
	Variable (Optional)	n	spm	35-55	35-55	20-35
Max. Die Shut Height		H2	mm	400	450	500
Die Shut Height Adjustment		t	mm	110	110	120
Side Window Size	F-B	E	mm	650	750	800
	Height	F	mm	350	420	430
Distance Between Uprights		G	mm	1100	1200	1300
Table Size	F-B	D	mm	650	750	800
	L-R	C	mm	1000	1100	1200
	Thickness	H3	mm	165	180	190
Table Hole Diameter			mm	180	200	200
Slide Bottom Size	F-B	b	mm	600	700	750
	L-R	a	mm	750	850	950
Table Surface Height		H1	mm	1005	1115	1205
Overall Dimensions	F-B	A	mm	2200	2300	2500
	L-R	B	mm	1780	2000	2050
	Height	H	mm	3800	4200	4500
Motor Power			kw	15	18.5	22
Weight (Approximate)			kg	16000	22000	27500

Company Features
1. The tight network of production bases, sales and service training stations of Shanghai Yingxin World Machinery Co., Ltd. is throughout the country.
2. We’ve worked with folks here and with countless companies across China (and beyond). By stressing the importance of a true relationship with each customer to ensure that we thoroughly understand all aspects of their business, we obtain many repeat purchases.
3. Shanghai Yingxin World Machinery Co., Ltd.'s operation philosophy is 'Respect everyone, provide high quality service, pursue excellence performance'. Ask online!
