WORLD h type power press high-Supply for customization

Place of Origin:

Jiangsu China

Payment:

L/C, T/T

MOQ:

Model:

JW31-315

Brand:

WORLD

Inquiry

Supply Ability

2000 Unit/Units per Year

Start Port

Shanghai China

Material

Metal

Delivery Time

60 days

Certification

CE, CCC

Availability

OEM

The JW31-315 Ton Single Punch Tablet Press Machine embodies precision and efficiency in pharmaceutical manufacturing. With a formidable 315-ton punching force, it effortlessly transforms raw materials into perfectly formed tablets, meeting the highest quality standards.

This machine's single punch design simplifies operation while ensuring consistent tablet production. Its robust construction and advanced technology guarantee durability and reliability even under demanding production conditions.

Equipped with user-friendly controls, the JW31-315 offers seamless operation and precise control over compression parameters. Its compact footprint maximizes floor space utilization, making it ideal for both large-scale production facilities and smaller laboratories.

From pharmaceuticals to nutraceuticals, this tablet press machine delivers exceptional performance, streamlining the manufacturing process and ensuring the efficient production of high-quality tablets.

Item		Code	Unit	JW31-315	JW31-400	JW31-500
Nominal Capacity		Pe	kn	3150	4000	5000
Slide Stroke		s	mm	220	250	250
Slide Stroke Speed	Fixed	n	spm	30	25	20
Slide Stroke Speed	Variable (Optional)	n	spm	20-35	20-30	15-25
Max. Die Shut Height		H2	mm	550	600	650
Die Shut Height Adjustment		t	mm	120	120	120
Side Window Size	F-B	E	mm	850	900	1000
Side Window Size	Height	F	mm	480	520	650
Distance Between Uprights		G	mm	1350	1450	1650
Table Size	F-B	D	mm	850	900	1000
	L-R	C	mm	1250	1350	1500
	Thickness	H3	mm	190	200	220
Table Hole Diameter			mm	220	220	220
Slide Bottom Size	F-B	b	mm	800	850	950
Slide Bottom Size	L-R	a	mm	1000	1100	1250
Table Surface Height		H1	mm	1215	1225	1225
Overall Dimensions	F-B	A	mm	2600	2700	3100
	L-R	B	mm	2200	2370	2600
	Height	H	mm	4550	4900	5400
Motor Power			kw	30	37	45
Weight (Approximate)			kg	30000	36500	47500

we welcome custom designs and ideas and is able to cater to the specific requirements. for more information, please visit the website or contact us directly with questions or inquiries.
