Wholesale hand power press machine manufacturers at discount

Company Advantages
1. The design of WORLD is created with care. It is defined as the use of imagination, scientific principles, and engineering techniques. The product will stop immediately once it is overload than 110% to protect both the press and the die
2. There is a cut in the payment of labor because the use of this product has replaced manual labor. It also helps reduce production time.It comes with a wide range of electric motor powers
3. Strict testing: its current performance has been tested by third parties. It is also ready to be tested by users and will be continuously updated. It is suitable for various kinds of fabrication work, such as the manufacturing of auto parts, household appliances, electronic parts, etc
4. Several tests have been carried out at each stage of production to ensure consistent product quality.

JH21-63L 63 Ton Stroke Adjustable Punching Machines

                                                              Specification List:

Model				JH21-63L
Capacity			kN	630
Nominal Stroke			mm	4
Slide Stroke			mm	10-150
SPM	Fixed		min-1	70
	Variable		min-1	60-80
Max. Die Height			mm	300
Die Height Adjustment			mm	80
Throat Depth			mm	300
Between Columns			mm	620
Bolster		LR	mm	900
		FB	mm	580
		Thickness	mm	110
Bolster Opening			mm	φ200×40
(Up Hole Dia.×Depth×Low Hole Dia.)				×φ180
Slide Area		LR	mm	680
		FB	mm	400
Shank Hole		Dia.	mm	φ50
		Depth	mm	80
Main Motor Power			kW	7.5
Dimensions		FB	mm	1680
		LR	mm	1260
		H	mm	3050
Net Weight			kg	6500

Company Features
1. In the fierce market competition, Shanghai Yingxin World Machinery Co., Ltd. has grown continuously. We have imported a series of flexible and modern production facilities. They are perfectly suited to offering scalable manufacture, from one-off custom design products, right up to bulk production runs.
2. After years of dedication to improving product quality, we have been selected as a business partner by many famous brands. This is strong proof of our ability in this field.
3. Our factory is backed by a series of advanced machines. They are equipped with the latest technologies to allow the testing and manufacture of our products with the best precision available. Shanghai Yingxin World Machinery Co., Ltd. aims to create a new brand of hand power press machine , creating a new market space. Contact us!
