Top 30 ton power press machine company for customization

Place of Origin:
Jiangsu China
Payment:
L/C, T/T
MOQ:
1
Model:
JW31-315
Brand:
WORLD
Inquiry
Supply Ability
2000 Unit/Units per Year
Start Port
Shanghai China
Material
Metal
Delivery Time
60 days
Certification
CE, CCC
Availability
OEM
Company Advantages
1. With rational construction, 30 ton power press machine takes on in a better way. Its table length and width can be customized to better operation
2. The potential application value of the product is worth discovering. The product is distinguished by low electricity consumption
3. The product is characterized by reliability. Its high-performance mechanical components make it highly adaptable to the changeable industrial environments. The ball bearing has high wear resistance, avoiding generating big gear noise due to abrasion
4. High dimensional accuracy is the prominent point of the product. Advanced cutting tools and techniques are applied to ensure its dimension precision. Adopting the hydraulic system, it needs little maintenance









Item
Code
Unit
JW31-315
JW31-400
JW31-500
Nominal Capacity
Pe
kn
3150
4000
5000
Slide Stroke
s
mm
220
250
250

Slide Stroke Speed
Fixed
n
spm
30
25
20
Variable (Optional)
n
spm
20-35
20-30
15-25
Max. Die Shut Height
H2
mm
550
600
650
Die Shut Height Adjustment
t
mm
120
120
120

Side Window Size
F-B
E
mm
850
900
1000
Height
F
mm
480
520
650
Distance Between Uprights
G
mm
1350
1450
1650

Table Size
F-B
D
mm
850
900
1000
L-R
C
mm
1250
1350
1500
Thickness
H3
mm
190
200
220
Table Hole Diameter

mm
220
220
220

Slide Bottom Size
F-B
b
mm
800
850
950
L-R
a
mm
1000
1100
1250
Table Surface Height
H1
mm
1215
1225
1225

Overall Dimensions
F-B
A
mm
2600
2700
3100
L-R
B
mm
2200
2370
2600
Height
H
mm
4550
4900
5400
Motor Power

kw
30
37
45
Weight (Approximate)

kg
30000
36500
47500









Company Features
1. Since establishment, Shanghai Yingxin World Machinery Co., Ltd. has been providing high performance services for the market.
2. We have an experienced resource purchasing and management team. They have many years of experience in materials purchases and profound knowledge in the industry trend. Hence, they can control the purchase costs effectively while guaranteeing high-quality materials.
3. Shanghai Yingxin World Machinery Co., Ltd. can provide customization service for our 30 ton power press machine . Please contact.
Contact us
we welcome custom designs and ideas and is able to cater to the specific requirements. for more information, please visit the website or contact us directly with questions or inquiries.
