Top mechanical press machine Suppliers for customization

Company Advantages
1. The quality of WORLD can be guaranteed. It is manufactured according to the requirements and standards of the SANYO company. Its top oil house has been tested by an oil bath to guarantee no leaking
2. Shanghai Yingxin World Machinery Co., Ltd. connects mechanical press machine products and services to supporting the customers. The clearance between connecting rod and slider has been eliminated to reduce force component impact and abrasion
3. The product has passed the tests on various quality parameters conducted by our experienced quality control team. The product is distinguished by low electricity consumption

Item		JX36-400	JX36-500	JX36-630	JX36-800	JX36-1000
Nominal Capacity	kn	400	5000	6300	8000	10000
Rated Tonnage Point	mm	9	12	12	12	12
Stoke Length	mm	300	300	350	350	400
Stroke Speed	spm	20-35	20-35	20-30	15-25	15-25
Max. Die Shut Height	mm	650	650	700	800	900
Die Shut Height Adjustment	mm	200	200	250	250	250
Table Size (FBxLR)	mm	1300×3000	1500×3000	1500×3600	2000×4000	2000×4000
Table Thickness	mm	220	220	250	250	250
Slide Bottom Size (FB-LR)	mm	1300×3000	1500×3000	1500×3600	2000×4000	2000×4000
Window Opening (FBxH)	mm	1000×650	1100×650	1200×700	1600×800	1600×900
Table Height	mm	710	710	710	710	710
Motor Power	kw	45	55	75	75	90
Overall Dimensions (LxWxH)	mm		3330x4650x 7250	3800x5400x 7700	4200x6150x 9200	4600x6150x 9900
Approximate Weight	t	80	90	120	150	190

Company Features
1. Shanghai Yingxin World Machinery Co., Ltd. has become a first-class domestic manufacturer that is widely recognized in the Chian market.
2. We have successfully explored overseas markets in North America, Southeast Asia, and some European countries. We have gained a piece of our share from the huge international marketplace.
3. As a provider of social obligations, we see it as an obligation to effectively handle energy and resources and prevent environmental hazards in all of our regions.
