Top automatic power press machine

Place of Origin:
Jiangsu China
Payment:
L/C, T/T
MOQ:
1
Model:
YW32-315
Brand:
WORLD
Inquiry
Supply Ability
1000 Unit/Units per Year
Start Port
Shanghai China
Material
Metal
Delivery Time
60 days
Certification
CE, CCC
Availability
OEM
Company Advantages
1. The development of WORLD has many design considerations. They are static and dynamic stiffness, operating speed, gearbox, manual and automatic control. The designing and versatility of the product give users an advantage of moving its freely around the workplace
2. This product will finally contribute to bringing profits for manufacturers. It helps cut expenditures both in labor and energy consumption. The ball bearing has high wear resistance, avoiding generating big gear noise due to abrasion
3. automatic power press machine can effectively and increasing the operating quality. It adopts pneumatic cylinder structure to avoid machine shaking caused by weight
4. Our automatic power press machine is not only beautiful but also durable.
5. makes automatic power press machine to be operated well. Its table length and width can be customized to better operation

Four Columu Presse Hydraulic Pressing Machine 100 Ton


Four column hydraulic press is applicable for drawing, bending, flanging, cold extruding and blanking process for metal materials. It is also applicable for adjusting, press-in and forming process for powder and abrasive products, plastic and insulation materials. The hydraulic press adopts 3 beam and 4 column compact structure, simple, economic and practical. Adopting button common control with two operation modes: adjustment or two hand single cycle operation. Preset stroke forming or preset pressure forming process can be selected.



MODELYW27-200YW27-315YW27-400YW27-400AYW27-400BYW27-500YW27-630
CapacitykN2000315020004000400050006300
Hydraulic cushion capacitykN1200150015002000100015002000
Slide Strokemm80010001000120050010001500
Hydraulic cushion Strokemm260300350350200300400
Max. Shut Heightmm1200160015002000110014002000
Bolster movement distancemm

20002400
16002700
Slide SpeedIdle Strokemm/s220200200250180220200
Pressingmm/s15-2510-159-1510-2510-258-206-15
Returnmm/s160150150150120160150
Ejecting SpeedEjectmm/s60606060608080
Returnmm/s1001001008080120100
Bolster SizeLRmm1000250027003000170020004500
FBmm1000160015002000140014002500
Main Motor PowerkW15224444444467
