    JH21-200 Single Crank Pneumatic Power Press Machine

    JH21 C frame mechanical power press machine (punching press, press machine, stamping press), capacity range from 25 ton to 400 ton. Welded steel body, heat treatment, shot blasting, better rigidness, accuracy and stability. PLC control, wet type combined pneumatic clutch and brake, hydraulic overload protected, auto lubricated. The press can work with NC feeder for automatic production.

    WET CLUTCH

    HYDRAULIC OVERLOAD PROTECTING PUMP

    AUTO LUBRICATION SYSTEM

    PRODUCT SPECIFICATION

    WORLD

    JH21-200 Ton Product Efficiency Stainless Steel Power Press 200 Ton Presses Machine 8
    JH21-200 Ton Product Efficiency Stainless Steel Power Press 200 Ton Presses Machine 9
    • Steel welded body, tempering treatment, high rigidity, accuracy and stability.

    • Cross located crankshaft, compact structure.

    • The crankshaft undergoes grinding treatment after high frequency quenching.

    • The crankshaft undergoes grinding treatment after high frequency quenching.

    • PLC control and imported safety dual valve.
    • Pneumatic dual balance cylinder, which balances the slide block and ounch weight to reduce noise and impact.
    • Wet clutch and hydraulic overload protected pump.
    • Both auto grease lubrication system and manual thin oil lubrication system.
    ITEMCODEUNITJH21-200
    Nominal CapacityPeKN2000
    Slide Stroke LengthSmm220
    Slide StrokesFixed
    spm45
    Variable(optional)
    spm30-55
    Max. Die Shut HeightH2mm450
    Die Shut Height Adjustmenttmm110
    Throat DepthC1mm430
    Distance Between Uprightsd1mm910
    Slide Bottom SizeFBbmm650
    LRamm880
    Shank Hole SizeDiameterdmm70
    DepthImm100
    Table SizeFBDmm840
    LRCmm1390
    ThicknessH3mm180
    Table Hole Diameter¢mm240
    Overall DimensionsFBAmm2600
    LRBmm1540
    HeightHmm3800
    Motor Power
    KW18.5
    Weight(approximate)
    kg19200


    DETAILS INTRODUCTION

    WORLD

    JH21-200 Ton Product Efficiency Stainless Steel Power Press 200 Ton Presses Machine 10

    Wet Clucth

    Wet type pneumatic clutch with imported clutch disc, NOK seals, lower noise and maintenance cost, longer service life.

    JH21-200 Ton Product Efficiency Stainless Steel Power Press 200 Ton Presses Machine 11

    HMI for Easy Operation

    HMI according to the working time or working stroke times.The press has both mechanical and electrical cam controllers. The precision is 0.1mm.

    JH21-200 Ton Product Efficiency Stainless Steel Power Press 200 Ton Presses Machine 12

    High Precision for Sheet Metal Punching

    JH21 C frame press uses rectangular type lengthened slide guides with bronze plates for higher guide precision.

    JH21-200 Ton Product Efficiency Stainless Steel Power Press 200 Ton Presses Machine 13

    Hydraulic Overload Protected

    The press is standard equipped with Japanese SHOWA hydraulic overload pump.

    APPLICATIONS

    WORLD

    JH21-125 C Frame Pneumatic Press Machine

    Adopt to sheet metal punching , cutting, bending, drawing,stamping,blanking and forging process
