Best ton press Supply for flanging

Company Advantages
1. The manufacturing process of WORLD includes profiles extruding, cutting, CNC machining, deburring, and surface treating. All of these procedures have to be inspected by the QC team to meet the highest requirements in the heat sink industry. The product will stop immediately once it is overload than 110% to protect both the press and the die
2. Less time and effort are needed to maintain this product over the years, therefore one can save energy and costs. It is suitable for various kinds of fabrication work, such as the manufacturing of auto parts, household appliances, electronic parts, etc
3. The reflectivity of this product is satisfying. The screen's multiple layers of diffusion material negate the washout effects of ambient light for sharp image clarity. It comes with a wide range of electric motor powers

Four Column Hydraulic Workshop Press Price 400 Ton Press Machines

  Four column hydraulic press is applicable for drawing, bending, flanging, cold extruding and blanking process for metal materials. It is also applicable for adjusting, press-in and forming process for powder and abrasive products, plastic and insulation materials. The hydraulic press adopts 3 beam and 4 column compact structure, simple, economic and practical. Adopting button common control with two operation modes: adjustment or two hand single cycle operation. Preset stroke forming or preset pressure forming process can be selected.

MODEL			YW27-200	YW27-315	YW27-400	YW27-400A	YW27-400B	YW27-500	YW27-630
Capacity		kN	2000	3150	2000	4000	4000	5000	6300
Hydraulic cushion capacity		kN	1200	1500	1500	2000	1000	1500	2000
Slide Stroke		mm	800	1000	1000	1200	500	1000	1500
Hydraulic cushion Stroke		mm	260	300	350	350	200	300	400
Max. Shut Height		mm	1200	1600	1500	2000	1100	1400	2000
Bolster movement distance		mm			2000	2400		1600	2700
Slide Speed	Idle Stroke	mm/s	220	200	200	250	180	220	200
	Pressing	mm/s	15-25	10-15	9-15	10-25	10-25	8-20	6-15
	Return	mm/s	160	150	150	150	120	160	150
Ejecting Speed	Eject	mm/s	60	60	60	60	60	80	80
	Return	mm/s	100	100	100	80	80	120	100
Bolster Size	LR	mm	1000	2500	2700	3000	1700	2000	4500
	FB	mm	1000	1600	1500	2000	1400	1400	2500
Main Motor Power		kW	15	22	44	44	44	44	67

Company Features
1. Shanghai Yingxin World Machinery Co., Ltd. is equipped with strong research strength, having an R&D team dedicated to developing all types of new ton press .
2. We have set environmental objectives and targets to reduce environmental impacts. We will enhance compliance in handling wastes and emissions, as well as set up resource conservation plans.
