WORLD punch press best factory price longer service life

Place of Origin:
Jiangsu China
Payment:
L/C, D/A, D/P, T/T, Western Union, MoneyGram, OA
MOQ:
1
Model:
JH21-25
Brand:
WORLD
Inquiry
Supply Ability
2000 Unit/Units per Year
Start Port
Shanghai China
Material
Metal
Delivery Time
30 days
Certification
CE, CCC
Availability
OEM, ODM, OEM/ODM
Product Details
With the dedication to pursue excellence, Yingxin strives for perfection in every detail.Yingxin has the ability to meet different needs. Hydraulic Bending Machine is available in multiple types and specifications. The quality is reliable and the price is reasonable.
  • WORLD punch press best factory price longer service life 5
Application Scope
Yingxin's Power Press Machine Manufacturers is commonly used in the following industries.Since the establishment, Yingxin has always been focusing on the R&D and production of Power Press Machine Manufacturers. With great production capability, we can provide customers with personalized solutions according to their needs.
  • WORLD punch press best factory price longer service life 6
Company Advantages
1. The material for WORLD c frame power press is carefully selected. Such properties and behaviors as strength, hardness, durability, flexibility, weight, resistance to heat and corrosion, electrical conductivity, and machinability are required.
2. We meet the quality standards as per the customer demands.
3. The use of this product helps people reduce their working hours and helps relieve them from tiring works and heavy tasks.
4. The product contributes a lot in employee costs. Its needs fewer workers to support its operation, which will lead to financial savings.


PRODUCT SPECIFICATION



  1. Steel welded body, tempering treatment, high rigidity, accuracy and stability.

  2. Cross located crankshaft, compact structure.

  3. The crankshaft undergoes grinding treatment after high frequency quenching.

  4. Lengthened rectangular guide-way with a surface of bronze plate.

  5. Pneumatic dual balance cylinder, which balances the slide block and ounch weight to reduce noise and impact.

  6. PLC control and imported safety dual valve.

  7. Wet clutch and hydraulic overload protected pump.

  8. Both auto grease lubrication system and manual thin oil lubrication system.

  9. Both electrical and mechanical cam controller with encoder.

  10.  Motorized slide adjustment (60ton and bigger presses)

  • ITEM

    CODEUNITJH21-25
    NominalCapacityPeKN250
    Slide Stroke Length5mm80
    Slide StrokesFixed
    spm100
    Variabled(optional)
    spm60-120
    Max.Die Shut HeightH2mm250
    Die Shut Height Adjustmenttmm50
    Throat DepthC1mm210
    Slide Bottom SizeFBbmm250
    LRamm360
    Shank Hole SizeDiameterdmm40
    Depthlmm65
    Table SizeFBDmm400
    LRCmm720
    ThicknessH3mm80
    Table Hole Diameter
    mm150
    Overall DimensionsFBAmm1500
    LRBmm945
    HeightHmm2120
    Motor Power
    KW3

    DETAILS INTRODUCTION




                                 Wet Clucth                                    Wet type pneumatic clutch with imported clutch          disc,NOK seals .Lower noise and maintenance                cost.Longerservice life .

++
WORLD punch press best factory price longer service life 7
WORLD punch press best factory price longer service life 8


High  Precision for Sheet Metal Punching and Stamping

    The press body is milling and boring by PAMA machine center.JH21 C framepress uses rectangular type lengthened slide guides with bronze plates for higher guide precision


++


HMI for Easy Operation

  HMI with setting function I/O monitor, counter and preset counter.Motorized slide adjustment with digita shut height indicator.precision is 0.1mm.


++
WORLD punch press best factory price longer service life 9
WORLD punch press best factory price longer service life 10

Siemens Motor

WORLD punch press best factory price longer service life 11

PLC control system


Company Features
1. We have advanced punch press to produce finest products.
2. The large production base greatly increase Shanghai Yingxin World Machinery Co., Ltd. ' production capacity.
3. c frame power press has become the perpetual pursuit of Shanghai Yingxin World Machinery Co., Ltd. to improve himself. Contact! power press punching machine has become the perpetual pursuit of Shanghai Yingxin World Machinery Co., Ltd. to improve himself. Contact! c frame power press manufacturers has become the perpetual pursuit of Shanghai Yingxin World Machinery Co., Ltd. to improve himself. Contact!





Mechanical hole punch Press



Application

Applied to punch holes which are missed out or punch holes required on the high pole tower.



Features

1)Hand operated
2)simple structure
3)Easy maintenance

4)safe and reliable



Technical Data of Machanical Hole Punch Press

 Product NO.
Model NO.
Thickness(mm)
Punching range(mm)
 Weight(kg)
 80301
SC-10
        4-9
Φ13.5- Φ 21.5
 13









Product Description

I would like to introduce our company as manufacturer of machines, dies, moulds, complete lines for many fields including sheet metal fabrication, dishing, rolling, foundry casting, converting, packing, etc...

We have been making machines with an experience of 40 years and we exporting to more than 60 countries worldwide.

You can see what we can supply you with at http://biko.makineturk.biz
