jackow@pressmachine-world.com+86-13817590728           WORLD power press machine manufacturer and supplier

WORLD power press machine price best factory price longer service life 1
WORLD power press machine price best factory price longer service life 2
WORLD power press machine price best factory price longer service life 3
WORLD power press machine price best factory price longer service life 4
WORLD power press machine price best factory price longer service life 1
WORLD power press machine price best factory price longer service life 2
WORLD power press machine price best factory price longer service life 3
WORLD power press machine price best factory price longer service life 4

WORLD power press machine price best factory price longer service life

Place of Origin:
Jiangsu China
Payment:
L/C, D/A, D/P, T/T, Western Union, MoneyGram, OA
MOQ:
1
Model:
JH21-25
Brand:
WORLD
Inquiry
Supply Ability
2000 Unit/Units per Year
Start Port
Shanghai China
Material
Metal
Delivery Time
30 days
Certification
CE, CCC
Availability
OEM, ODM, OEM/ODM
Product Comparison
Power Press Machine Manufacturers has the following advantages: well-chosen materials, reasonable design, stable performance, excellent quality, and affordable price. Such a product is up to the market demand.Yingxin's Power Press Machine Manufacturers has the following advantages over other similar products.
  • WORLD power press machine price best factory price longer service life 5
    WORLD power press machine price best factory price longer service life 6
Company Advantages
1. WORLD power press machine for sale undergoes a complete set of the production process. Especially the battery part has to go through welding, inspection, stamping, burr removing, pressure testing, and component testing.
2. The product is resistant to weather resistance. It is able to withstand sunlight, temperature, ozone, and inclement weather conditions (rain, hail, sleet, snow, etc.).
3. As a professional power press machine price manufacturer, WORLD will be confident enough to provide power press and power press machine for sale .
4. Technology progress of Shanghai Yingxin World Machinery Co., Ltd. relies on power press machine price R&D capabilities.


PRODUCT SPECIFICATION



  1. Steel welded body, tempering treatment, high rigidity, accuracy and stability.

  2. Cross located crankshaft, compact structure.

  3. The crankshaft undergoes grinding treatment after high frequency quenching.

  4. Lengthened rectangular guide-way with a surface of bronze plate.

  5. Pneumatic dual balance cylinder, which balances the slide block and ounch weight to reduce noise and impact.

  6. PLC control and imported safety dual valve.

  7. Wet clutch and hydraulic overload protected pump.

  8. Both auto grease lubrication system and manual thin oil lubrication system.

  9. Both electrical and mechanical cam controller with encoder.

  10.  Motorized slide adjustment (60ton and bigger presses)

  • ITEM

    CODEUNITJH21-25
    NominalCapacityPeKN250
    Slide Stroke Length5mm80
    Slide StrokesFixed
    spm100
    Variabled(optional)
    spm60-120
    Max.Die Shut HeightH2mm250
    Die Shut Height Adjustmenttmm50
    Throat DepthC1mm210
    Slide Bottom SizeFBbmm250
    LRamm360
    Shank Hole SizeDiameterdmm40
    Depthlmm65
    Table SizeFBDmm400
    LRCmm720
    ThicknessH3mm80
    Table Hole Diameter
    mm150
    Overall DimensionsFBAmm1500
    LRBmm945
    HeightHmm2120
    Motor Power
    KW3

    DETAILS INTRODUCTION




                                 Wet Clucth                                    Wet type pneumatic clutch with imported clutch          disc,NOK seals .Lower noise and maintenance                cost.Longerservice life .

++
WORLD power press machine price best factory price longer service life 7
WORLD power press machine price best factory price longer service life 8


High  Precision for Sheet Metal Punching and Stamping

    The press body is milling and boring by PAMA machine center.JH21 C framepress uses rectangular type lengthened slide guides with bronze plates for higher guide precision


++


HMI for Easy Operation

  HMI with setting function I/O monitor, counter and preset counter.Motorized slide adjustment with digita shut height indicator.precision is 0.1mm.


++
WORLD power press machine price best factory price longer service life 9
WORLD power press machine price best factory price longer service life 10

Siemens Motor

WORLD power press machine price best factory price longer service life 11

PLC control system


Company Features
1. Shanghai Yingxin World Machinery Co., Ltd. introduced core technologies for high proficiency and high quality of power press machine price .
2. Considering the economical factor, WORLD is working with the most reliable supplier to provide the most favoured price of the best power press .
3. Shanghai Yingxin World Machinery Co., Ltd. will guarantee greater customer satisfaction throughout the purchasing procedure. Get info! The raw materials used in the power press machine for sale are subject to strict raw material inspection. Shanghai Yingxin World Machinery Co., Ltd. sticks to the going-out strategy and aims to be an international brand. The vision of Shanghai Yingxin World Machinery Co., Ltd. is to become a worldwide provider of punch press. Get info!
